good afternoon!
Any news?
Can I restore the flash?
Хорошая статья, для тех кто не в теме.
Ссылка на эту статью со страницы flashboot.ru/files/file/319/ ведет не туда, куда надо.
flashboot.ru/bootable_flash/2012/11/05/windows-ewf.html — это мимо.
no mptool for new sss sory
you can extract nand and install on sm3257enba
  • avatar kdr
  • 0
А какая связь этой утилиты к этой статье?
f500 is alcor au6989sn-gtc

use ALCOR_MP_v16.09.30.00
low level
ecc=15
capacity mode
bad block=min=200 max=1850 mb
Мне флешка 2Гб. мне надо утилита.
Volume: G:
Controller: Alcor 0xF500
Possible Memory Chip(s):
Samsung K9ACGD8U0D
Memory Type: TLC
Flash ID: ECDE88BF 90C6
Flash CE: 1
Chip F/W: FD00
Group: 98
VID: 058F
PID: 6387
Manufacturer: Generic
Product: Mass Storage
Query Vendor ID: Generic
Query Product ID: Flash Disk
Query Product Revision: 8.07
Physical Disk Capacity: 2023751680 Bytes
Windows Disk Capacity: 0 Bytes
Internal Tags: AYAR-SY52
USB Version: 2.00
Declared Power: 200 mA
ContMeas ID: 8B6C-09-00
Microsoft Windows 7 SP1 Build 7601
Thanks for all, I will try
alcor mp 13.02.5

use chipgnuis for report controller but nand is 24bit ecc so au6990 is your ic
Спасибо за отклик. Скачал, установил, проверил:
Logical drive: F:\ Capacity: 0.0G
Device ID: VID = 058F PID = 9380
Device SN:
Device version: 7.76

Device vendor: Generic
Device model: USB Flash Disk
Protocol: USB2.0
Max power: 100mA

Partition type:! Device active: no
Aligned state: 0 KB, Have been Aligned

Controller: AlcorMP
Controller model: AU9380/9385/9386/SC708 Help?
Flash Vendor: Toshiba, Type: MLC, Single channel, Total: 2G
Flash ID: 98D59432 Flash Part: TC58NVG4D2ETA00
Score: 20 (Normal Score >= 30)
Tools: www.upan.cc/tools/mass/Alcor/
OS Version: Windows 8 Professional
Update Status: The current version is the latest version!

Попробую найти нужную утилиту
nand is brocked sorry
try on uptool 2092h
i cant trust 2093
in last uptool support 1e0

but new 2268 is 1e2 or 1e6
so i think you undrstand why uptool give you «cant isp found»

so fix that and say result
look this

OS Version: Win XP

MP Version: 2.093 (2015.01.14)

PC Name: []

DUT Slot: 1

Driver: G

IC Type: 1E-2

ISP Type: 1

F-Slot: 1
copy and paste in code.ini

new 2268 hardware model is 1e2 or 1e6
first in report see ic model 1e2?

uptool support old 2268 but if you add line can be fixed
[0x1E-2-0] // UP25AA — MLC
ISPCode=ISP61.bin
BurnerCode=BN61V114u-9.bin
FWCode0=226X-D2FW-141031-SVN947.bin ;// (30) non-T19 D2 Block
FWCode1=226X-D2FW-141031-SVN947.bin ;// (30) T19 eD2
FWCode2=226X-D2FW-141031-SVN947.bin ;// (30) T24/32 non-T19 D2 PageMode
FWCode3=226X-D2FW-141031-SVN947.bin ;// (3B) B74A
FWCode4=226X-D2FW-141031-SVN947.bin ;// (3B) B74A Page/Skip
FWCode5=226X-D2FW-141031-FASTRN-SVN946.bin ;// Full Block mode
FWCode6=226X-D2FW-141024-PBA-SVN909.BIN ;// PBA
FWCode7=226X-D2FW-141016-SVN884-CB.bin ;// CopyBack
FWCode8=226X-D2FW-140916-MULTIWRITE-SVN791.bin ;// MultiWrite mode
FWCode9=226X-D2FW-140916-FASTRNMULTIWRITE-SVN791.bin ;// MultiWrite mode+FastRN
FWCode10=226X-D2FW-141031-SVN947.bin
FWCode11=226X-D2FW-141031-FASTRN-SVN946.bin
  • avatar hasan64
  • 0
i use UPTool_Ver2093(Release)_20150312 but after 1:55:09 time ERROR code plz help
  • avatar hasan64
  • 0
cant find firmware for ps2251-68 teamGroup 16GB

Logical drive: F:\ Capacity: 0.0G
Device ID: VID = 13FE PID = 3E00
Device SN:
Device version: 1.00

Device vendor:
Device model: 2268 PRAM
Protocol: USB2.0
Max power: 50mA

Partition type: Device active:
Aligned state: Misaligned

Controller: Phison
Controller model: PS2251-68
Flash Vendor: Toshiba, Type: MLC
Flash ID: 983A9493
Score: 60 (Normal Score >= 30)
Firmware: 01.02.10 FW Date: 2015.03.25

Tools: www.upan.cc/tools/mass/Phison/
OS Version: Windows 8 Professional
Update Status: The current version is the latest version!
  • avatar hasan64
  • 0
my toshiba with sss controller flash id is 0000 ?????
Description: [H:]USB Mass Storage Device(hp v210w)
Device Type: Mass Storage Device

Protocal Version: USB 2.00
Current Speed: High Speed
Max Current: 200mA

USB Device ID: VID = 03F0 PID = 5607
Serial Number: 07A9020096760A51

Device Vendor: HP
Device Name: v210w
Device Revision: 0100

Manufacturer: hp
Product Model: v210w
Product Revision: PMAP

Controller Vendor: Phison
Controller Part-Number: PS2251-50(PS2250) — F/W 02.06.10 [2009-12-01]
Flash ID code: 98D79432 — Toshiba TC58NVG5D2FTA00 [MLC-8K]

Tools on web: dl.mydigit.net/special/up/phison.html

Possible Flash Part-Number
— [1CE]TC58NVG5D2FTA00(32nm)
[1CE]TC58NVG5D2ELA48(43nm)
[1CE]TC58NVG5D2FTA10(32nm)
[2CE]TC58NVG6D2FTA20(43nm)
[4CE]TC58NVG7D2ELA48(43nm)

Flash ID mapping table
— [Channel 0] [Channel 1]
